| Specification | Description |
|---|---|
| Bar Capacity | 12 mm |
| Max Machining Length (80mm: Rotary guide bushing) | 210 mm |
| Max Main Spindle Drilling Diameter | Ø7 |
| Max Main Spindle Tapping Diameter | M6 X 1 |
| Max Back Spindle Barstock Diameter | Ø12 |
| Max Back Spindle Drilling Diameter | Ø7 |
| Max Back Spindle Tapping Diameter | M6 x 1 |
| Max Cross Drilling Diameter (OP.) | Ø6 |
| Max Cross Tapping Diameter (OP.) | M5 X 0.8 |
| Spindle Speeds (Main) | 200 - 12,000 RPM |
| Spindle Speeds (Sub) | 200 - 12,000 RPM |
| Tool Storage Capacity | 17 |
| Tool Size | 12mm x 12mm x 85mm |
| Machine Dimensions | 65" x 41" x 67" |
| Weight | 3,970 Lbs. |
