| Specification | Description |
|---|---|
| Bar Capacity | 7 mm |
| Max Machining Range | 70 mm |
| Max Machining Diameter | 4 mm |
| Max Main Spindle Drilling Diameter | Ø7 |
| Max Tapping Diameter | M4 X 0.7 |
| Sub Spindle Max Chuckable Diameter | 7 mm |
| Spindle Speeds (Main) | 200 - 15,000 RPM |
| Spindle Speeds (Sub) | 200 - 10,000 RPM |
| Tool Storage Capacity | 8 Outer, 3 Drilling |
| Tool Size | 7 X 85 mm |
| Machine Dimensions | 52" x 36" x 66" |
| Weight | 3,530 Lbs. |
