| Specification | Description |
|---|---|
| Table Sizes | 8.25" X 28.75" |
| Longitudinal Travel | 18.125" |
| Cross Travel | 7.5" |
| Number of Spindle Speeds | 12 |
| Spindle Speeds | 50 - 2,500 RPM |
| Spindle Travel Length | 5" |
| Spindle Taper Size | R8 |
| Drilling Capacity in Steel | 1.25" |
| Drilling Capacity in Cast Iron | 1.25" |
| Tapping Capacity in Steel | 0.625" |
| Quill Diameter | 4.5276" |
| Spindle Power Feed Rate Per Minute | 0.12; 0.18; 0.25 (mm/rev) |
| Maximum Spindle To Column Distance | 8.0709" |
