| Specification | Description |
|---|---|
| Rectangular Capacity | 15" X 17" |
| Round Capacity | 15" |
| Blade Size | 1 1/4" X 0.035 X 14' 5" |
| Blade Speed | 75 - 300 Feet per Minute |
| Tension System | Hydraulic |
| Blade Guides | Ball Bearings w/ Cabide Blocks |
| Blade Wheel Diameter | 20" |
| Cutting Force | 30 - 200 lbs. |
| Clearance Under Blade | 16" |
| Cut Return Time | 17" in 12 Sec. |
| Blade Motor | 3 HP |
| Hydraulic Pump Motor | 1.5 HP |
| Coolant Pump Motor | 200 Watts |
| Coolant Tank | 10.5 Gallons |
| Coolant Tank Pump | 3.3 GPM |
| Work Load | 3,000 lbs. |
| Floor Space | 88" X 52" X 71" |
| Weight (Approx.) | 1,850 lbs, |
