| Specification | Description |
|---|---|
| Work Piece Surface | 25.98" X 13.77" (2 Pallets) |
| X Travel | 17.71" |
| Y Travel | 10.63" |
| Z Travel | 12.2" |
| Spindle Speeds | 30,000 RPM |
| Spindle Motor | 7.2 kW |
| Spindle Taper | HSK-A 40 |
| Tool Capacity | 24 |
| Workpiece Changing Device (Spin) | 0° / 180° |
| Drill Capacity in St 60 with inserted Drill | Ø 16 mm |
| Thread Cutting | M 12 |
| Max. Tool Diameter | 47 mm |
| Max. Tool Length | 160 mm |
| Max. Tool Weight | 1.2 kg |
| Tool Change Time | 0.8 s |
| Chip to Chip Time (approx.) | 2.4 s |
| Max. Speed Thread Cutting | 8,000 RPM |
| Load Capacity per Table Side | 440 Lbs. |
