| Specification | Description |
|---|---|
| Table Size | 23.5" x 17.25" |
| Table Travel | 21" X 12" |
| Work Tank | 27.25" x 19.25" |
| Minimum Ram Height to Table | 1" |
| Electro-Guide Travel | 15.5" |
| (X) Travel | 21" |
| (Y) Travel | 12" |
| (Z) Travel | 25.6 |
| W Axis Power Backslide | 11.3" |
| Electrode Size | 0.1 - 3.0 mm Dia x 635 mm Long |
| Maximum Z Motor Axis Travel with Chuck | 15.5" |
| Maximum Work Piece Weight | 675 Lbs. |
| Maximum Work Piece Height | 15.5" |
| Tool Capacity | 22 Station |
| Peak Current Selections | 10 Steps |
| Voltage Selections | 3 Steps |
| Pulse On Time Settings | 0 - 100% |
| Pulse Off Time Settings | 0 - 100% |
| Electrode Spindle Speeds | 0 - 200 RPM |
| Capacitors | 5 Steps |
| Machine Dimensions | 72" L x 48" W x 96"H |
| Machine Weight (w/Filtration Unit) | 3,000 Lbs. |
| Voltage Power | 208 - 220V /3 Phase |
