| Specification | Description |
|---|---|
| Swing Over Bed | 14" |
| Swing Over Ways | 8.5" |
| Distance Between Centers | 32" |
| Length of Bed | 40" |
| Spindle Speed (Lo / Hi) | 50 - 300; 300 -1800 RPM |
| Diameter of Spindle Hole | 1.5" |
| Number of Threads and Feeds | 48 |
| Threads Per Inch | 4 TO 224 |
| Longtudinal Feeds | 0.0015 - 0.0841 |
| Wired | 220v / 3 Ph |
| Foot Print | 70" (LR) x 27" (FB) x 52" (T) |
