| Specification | Description |
|---|---|
| Table Size | 20 1/2" X 23 3/4" |
| Drilling Capacity | 2 1/8" (Steel) |
| Morse Taper | #5 |
| Center Spindle to Column | 14.5" |
| Column Diameter | 7 7/8" |
| Spindle Motor | 6 1/2 HP |
| Coolant Pump Motor | 1/4 HP |
| Spindle Travel | 10" |
| Spindle to Table | 4" to 28 3/4" |
| Spindle to Base | 51" (Maximum) |
| Spindle Speed Ranges (9 Speed Ranges) | 54 to 1,338 RPM |
| Feed Rates (4) | 0.003 to 0.013 IPR |
| T-Slot Table | 1" (3) Table, (2) Base |
| Vertical Travel of Table | 24 1/2" |
| Weight | 2,000 lbs. |
