| Specification | Description |
|---|---|
| Table Size | 50" x 30" |
| Power or Hand Feed Quill Travel | 6" |
| X Travel | 35" |
| Y Travel | 19" |
| Z Travel | 22.5" |
| Spindle Speeds | 40 - 6,000 RPM |
| Spindle Taper | #40 |
| Spindle to Column Distance | 20" |
| Rapid Traverse (X/Y/Z): | 500 / 500 / 300 IPM |
| Table Load | 1,500 Lbs. |
| Spindle Motor | 7.5 HP |
| Wired | 230 Volt 3-Phase |
| Foot Print | 84" x 75" x 94" Tall |
| Weight (approx) | 6,000 Lbs. |
